Specifications
ENGINE
Duromax XP18HPX / 439 cc
HORSEPOWER CLASS
18 hp / 13.4 kW
FUEL TYPE
Gasoline and Propane
ROTOR DIAMETER
36 in (4-blades) / 91 cm
MAXIMUM ROTOR SPEED
120 rpm
TROWEL ARMS & SPIDER
Standard Duty
WEIGHT
246 lb / 111.6 kg
DIMENSIONS (L X W X H)
72 x 38 x 36 in / 182.8 x 96.5 x 91.4 cm
Equipment Videos
Walk Behind Trowels
06:04 Min
This video gives instructions on how to properly complete the alignment of a trowel arm jig on a walk-behind or ride-on trowel.
Walk Behind Trowels
02:49 Min
This video gives you instructions on how to properly check the flatness of your trowel arms for walk-behind and ride-on trowels.
FAQ's
My Walk-Behind Trowel positive pitch drifts down
Check the ¾” adjusting nut on the positive pitch clutch.
Walk-Behind Trowel is shredding belts
1. Make sure you have the correct belt.
2. Check belt alignment.
How do I keep my pitch handle from falling while operating the machine?
Make sure the set screws in the collar bushing are catching the intentions on the shaft.
What do I do if my machine is spinning at idle?
1. Check belt alignment.
2. Check engine idle.
Why is my walk-behind wobbling?
Look for a bent arm or trowel arm out of alignment.
Can I get replacement springs and weights for my clutch?
Yes, we offer replacement springs and weights per model. Please refer to the respected parts manual.
