Product Listing Based on Machine Specs

Filter By

AUGERS

Dual 8 in Adjustable

AVAILABLE SECTIONS

2 ft 5 ft or 7 ft

3 ft 6 ft or 12 ft

BOGIES

24" Power Drive Bogie Frames w/ Cupped Wheels and 24" Idle Bogie Frames w/ Cupped Wheels

36" Power Drive Bogie Frames w/ Cupped Wheels and 36" Idle Bogie Frames w/ Cupped Wheels

BOGIES-DRIVER

Two Cupped Wheels - 36 in

Two Cupped Wheels - 48 in

BOGIES-IDLE

Two Cupped Wheels - 36 in

Two Cupped Wheels - 48 in

CRAWLER TRACK LENGTH

10 ft or 12 ft

6.4 ft

DISCLAIMERS

*Consult with factory on equipment needed. **Machine to be transported with pan flat and not raised.

ENGINE

Air-Cooled KOHLER CH440

Air-Cooled KOHLER CH440 or KOHLER CH740

Hatz 3H50TIC (T4F)

Hatz 4H50TIC (T4F)

HATZ T4

HONDA EFI

John Deere 4.5L (T4F)

KOHLER CH395

KOHLER ECH1000 EFI

FRAME DIMENSIONS (D X W)

12 x 24 in

18 x 24 in

24 x 34 in

FUEL RESERVOIR

110 gal

24 gal

FUEL TYPE

Air-Cooler Gasoline

Diesel

Gasoline

Gasoline (Diesel option available)

Liquid-Cooled Diesel

HEAVY DUTY MATERIAL CONVEYOR

Standard

HORSEPOWER CLASS

14 hp

14 hp or 23.5 hp

173 hp

22 hp

23.5 hp

37 hp

49.5 hp

74 hp

9.5 HP

HYDRAULIC OIL RESERVOIR

100 gal

13.5 gal

25 gal

30 gal

42 gal

60 gal

9 gal

HYDRAULIC SPRAY SYSTEM

OPTION

Standard

HYDRAULIC STEERING LEG

OPTION

Standard

LEGS (WITH SOLID LEG PLATES)

Manual 6 in or Powered 6 in

Powered 6 in

LEGS HEIGHT ADJUSTMENT

44 in (Vertical Adjustment)

48 in (Vertical Adjustment)

MAIN FRAME

2x 12' x 24' Truss Sections w/ Leg Rail

2x 15' x 36' Truss Sections w/ Leg Rail

MAINFRAME

Height 28 ¼” (717 mm), Width 3’ (.91 M), Length 13’ 8” (4.17 M) at 8’ paving width

Mainframe Hydraulic Systems & Power Unit*

Utilizes the Auxiliary hydraulics from Compact Track/Skid Steer Loader

MAX WORK BRIDGE LENGTH

120 ft

52.5 ft

90 ft

MAXIMUM WIDTH

120 ft

90 ft

OPERATOR'S CONSOLE ENGINE

Air Cooled KOHLER CH740

PAVING CARRIAGE ENGINE

Air Cooled KOHLER CH740

PAVING DEPTH

Up to 6 in

PAVING PAN

3/16” Steel paving pan attached to mainframe by Vibration isolators (Note: 10 cu ft hopper when assembled in the 8’ paving mode)

PAVING PROFILE HEADS

2x 12' sections / 4 Paving Profile Heads comes with Base Machine

2x 15' sections / 4 Paving Profile Heads comes with Base Machine

PAVING ROLLERS

Dual 48 in

Dual 60 in

PAVING WIDTH OPTION 1:

8’ (2.43 M) Maximum width paving assembly (Configured with 3’ Section, 3’ Section & 2’ Section)

PAVING WIDTH OPTION 2:

6’ (1.8 M) (Configured with 3’ Section & 3’ Section)

PAVING WIDTH OPTION 3:

5’ (1.5 M) (Configured with 3’ Section & 2’ Section)

PAVING WIDTH OPTION 4:

3’ (.91 M) Minimum width paving assembly

PAVING WIDTHS

12 ft

12 ft or 16 ft

ROLLER TUBE DIAMETER

10 in

6" or 8"

6.625 in

SECTION WIDTHS AVAILABLE

3, 4, 6, 12 and 15 ft

TELESCOPIC SECTIONS

15 - 25 ft

Transport Dimensions**

Transport Width (assembled) – 36” Length – 13’ 8” Machine weight at 8’ paving width – 2,500 lbs.

TUBE WEIGHT PER FT

19 / 21 lbs

19 lb

27 lb

VIBRATION SYSTEM

6 Hydraulic Pan Vibrators

6 or 8 Hydraulic Pan Vibrators

VIBRATION SYSTEMS

(3) M-1200 Vibrator circuits with individual variable controls (24” on Center Spacing)

VIBRATOR DEPTH

24" Below Grade

VIBRATOR FREQUENCY

11,000 vpm

WEIGHT

14,000 lbs

2,626 lbs

28,500 lbs

WEIGHT AT 22 FT

2,790 lb

5,570 lb

8,700 lb

WIDTHS AVAILABLE (2 FT INCREMENTS)

12 – 32 ft

12 – 34 ft

14 – 22 ft
